Symbol and Footprint Database for Electronic Components by Agentic Recognition and Generation

A rich and recognizable component library is the cornerstone of printed circuit board (PCB) design and generation. Traditionally, engineers manually create symbols and footprints and design PCB schematics, which is time-consuming and error-prone. Leveraging multimodal large language models (MLLMs), we develop SFgen, an agentic recognition and generation flow of symbol and footprint for electronic components. SFgen achieves 86% accuracy for symbol generation and 80% accuracy for footprint generation. We use the SFgen method to create SFnet, a database of symbols and footprints. It now has 1000 components and is expanding constantly, which lays the foundation for automatic generation of PCB designs.
